R&S®MXO 5C Oscilloscope

Next generation oscilloscope in a compact form

R&S®MXO 5C Oscilloscope
Open Lightbox
R&S®MXO 5C Oscilloscope
Open Lightbox
R&S®MXO 5C Oscilloscope
Open Lightbox
R&S®MXO 5C Oscilloscope
Open Lightbox
R&S®MXO 5C Oscilloscope
Open Lightbox
R&S®MXO 5C Oscilloscope
Open Lightbox
R&S®MXO 5C oscilloscope, front low R&S®MXO 5C oscilloscope, front low R&S®MXO 5C oscilloscope, back low R&S®MXO 5C oscilloscope, hero view R&S®MXO 5C oscilloscope, application image R&S®MXO 5C oscilloscope, application image

Key facts

  • Bandwidth: 4 channel: 350 MHz - 2 GHz | 8 channel: 100 MHz - 2 GHz
  • 2U height which makes it the ideal choice for rack applications
  • Integrated e-ink display with key information such as instrument IP and status for fast setup
  • Zone Trigger on analog, spectrum, and math
  • Same great specs as MXO5 Series oscilloscope:
    - World’s fastest oscilloscope: 4.5 million waveforms/sec
    - Industry-leading system architecture: 12-bit ADC, 18 bi t HD mode and 10-bit ENOB
    - Deepest in class standard memory: 500 Mpoints
    - Industry leading spectrum acquisition rate of 45,000 FFT/s and up to 4 spectra

Starting at CAD 24,900

Next generation oscilloscope in a compact form

The R&S®MXO 5C series uses same building blocks as R&S®MXO 5 series oscilloscopes delving the same outstanding specifications, engineered into a compact form. The R&S®MXO 5C four-channel and eight-channel models and bandwidth ranging from 100 MHz up to 2 GHz provide superior time and frequency measurements. The 2U height of the R&S®MXO 5C series has the high channel density you need. It can be placed on a rack with other test equipment or used in bench applications for more vertical space. The paper-like low-power e-ink display shows key information such as connectivity status. The oscilloscope can be controlled remotely via LAN with the integrated web browser and virtual front panel.

Features & benefits

Benefit from the same great specs as the MXO 5 series

… in a compact form


  • World's first 8-channel oscilloscope to achieve > 4.5 million acquisitions and up to 90% real-time signal capture
  • Highest precision of 12-bit ADC/18-bit HD resolutions
  • Deep memory capture with 500 Mpoints per channel
  • Highest sensitivity with advanced digital trigger

R&S®MXO 5C series: the compact oscilloscope with the same great specs as the R&S®MXO 5 series
Open Lightbox

R&S®MXO 5C series: the compact oscilloscope with the same great specs as the R&S®MXO 5 series

Rack it or stack it

… thanks to its compact form


  • 4 or 8 simultaneous channels per 2U rackmount height.
  • Ideal for bench applications where vertical space is needed
  • Stack on an extra MXO 5 or MXO 5C series to get up to 16 channels.

With its 2U height, the oscilloscope is ideal for racks
Open Lightbox

With its 2U height, the oscilloscope is ideal for racks

See your signals on a big display

…or touchscreen of your choice


  • Add any full-HD compatible display for greater display area
  • Connect via standard HDMI or DisplayPort.
  • Choose a display with USB based touch capabilities that can be used just like the integrated screen on the MXO 5 series oscilloscope

Connect it to a touch screen
Open Lightbox

Connect it to a touch screen

Easily access your scope remotely

… and work from anywhere


  • Connect via LAN with the integrated web browser and virtual front panel
  • The virtual front panel display has virtual MXO5 dials/buttons.
  • 100% SCPI commands, waveform and saveset file compatibility with MXO 4 and MXO 5 series

Access your oscilloscope from anywhere
Open Lightbox

Access your oscilloscope from anywhere

Available models

Available models
Models
Bandwidth
Channels
Starting at

R&S®MXO5C-43

Order number 1802.3000P43

Bandwidth
350 MHz
Channels
4
Starting at
CAD 24,900

R&S®MXO5C-45

Order number 1802.3000P45

Bandwidth
500 MHz
Channels
4
Starting at
CAD 31,100

R&S®MXO5C-410

Order number 1802.3000P41

Bandwidth
1 GHz
Channels
4
Starting at
CAD 39,300

R&S®MXO5C-420

Order number 1802.3000P42

Bandwidth
2 GHz
Channels
4
Starting at
CAD 44,100

R&S®MXO5C-81

Order number 1802.3000P81

Bandwidth
100 MHz
Channels
8
Starting at
CAD 27,600

R&S®MXO5C-82

Order number 1802.3000P82

Bandwidth
200 MHz
Channels
8
Starting at
CAD 33,000

R&S®MXO5C-83

Order number 1802.3000P83

Bandwidth
350 MHz
Channels
8
Starting at
CAD 40,600

R&S®MXO5C-85

Order number 1802.3000P85

Bandwidth
500 MHz
Channels
8
Starting at
CAD 51,300

R&S®MXO5C-810

Order number 1802.3000P91

Bandwidth
1 GHz
Channels
8
Starting at
CAD 65,100

R&S®MXO5C-820

Order number 1802.3000P92

Bandwidth
2 GHz
Channels
8
Starting at
CAD 72,800
Specifications
Vertical system
Analog channels 4, 8
Digital channels (opt.) 16
Analog bandwidth (–3 dB) R&S®MXO54C with (B4x options)  350 MHz, 500 MHz, 1 GHz, 2 GHz
R&S®MXO58C with (B8x option) 100 MHz, 200, 350 MHz, 500 MHz, 1 GHz, 2 GHz
Rise time at 2 GHz bandwidth 234 ps
Input impedance 50 Ω ± 1.5 %,
1 MΩ ± 1 % || 12 pF (meas.)
Input sensitivity at 50 Ω 0.5 mV/div to 3 V/div, support entire analog bandwidth
at 1 MΩ 0.5 mV/div to 10 V/div,  support entire analog bandwidth
Vertical resolution up to 18 bit with HD mode (high definition)
DC gain accuracy input sensitivity > 5 mV/div ±1 % full scale
Offset range at 50 Ω < 33 mV/div ±(2 V – input sensitivity × position)
33 mV/div to < 120 mV/div ±(7 V – input sensitivity × position)
Offset range at 1 MΩ 0.5 mV/div to < 80 mV/div ±(5 V – input sensitivity × position)
80 mV/div to < 800 mV/div ±50 V
Channel-to-channel isolation > 60 dB (1:1000)
Acquisition system
Sampling rate analog channels (real time) max. 5 Gsample/s on 2 channels,
max. 2.5 Gsample/s on 4 channels
analog channels (interpolated) max. 5 Tsample/s
digital channels max. 5 Gsample/s on each channel
Acquisition memory Standard: R&S®MXO58C, 8-channel instrument max 500 Mpoints with 8 active channels (single capture)
max. 500 Mpoints with 4 active channels (run continuous)
Standard:R&S®MXO54C, 4-channel instrument: max. 500 Mpoints (single and run continuous)
Optional  R&S®MXO5C-B110 memory option 1 Gpoints max. 1 Gpoints with 4 active channels (single capture)
max. 1 Gpoints with 2 active channels (run continuous)
History segments ≤ 1 Mpoints record length 1 million segments
Max. acquisition rate > 4 500 000 waveforms/s
Acquisition modes sample, peak detect, average, envelope
Interpolation modes linear, sin(x)/x, sample & hold
Horizontal system
Timebase range Selectable between 200 ps/div and 10 000 s/div

Timebase accuracy after delivery/calibration, at +23 °C ±0.2 ppm
During calibration interval ±1 ppm
Channel-to-channel skew between analog channels < 100 ps (meas.)
between digital channels < 500 ps (meas.)
Trigger system
Standard trigger types Edge, glitch, width, runt, window, timeout, interval, slew rate, setup and hold, pattern, state, zone trigger
Advanced trigger modes A/B/R, serial bus, trigger in and out
Trigger sensitivity 0.0001 div, from DC to instrument bandwidth for all
vertical scales
Analysis and measurement
Automatic measurements 39
Cursor measurements 4
Waveform mathematics Up to 8 equations math on math (add, subtract, multiply, divide, absolute value, square, square root, integrate, differentiate, log10, loge, log2, reciprocal, invert, low pass, high pass, rescale (a*x+b))
Logic analyzer (MSO) functionality
Digital input channels 16
MSO Bandwidth 400 MHz
MSO sampling rate 5 Gsamples/s per channel
General data
Dimensions W × H × D 445 mm × 105 mm × 405 mm
(17.51 in × 4.13 in × 15.94 in)
Weight without options, nominal 8.7 kg (19.18 lb)
Rackmount height with R&S®ZZA-KN2NS rackmount kit 2 HU
Interfaces Front 3 × USB 3.1 Gen 1 ports, type A plug
Rear 2 × USB 3.1 Gen1 ports, type A plug
RJ-45 connector, supports 10/100/1000BASE-T
HDMI™ 2.0 and DisplayPort++ 1.3, output of oscilloscope display

Available options

Bandwidth upgrade
Product
Description
R&S®MXO5C-B405

Order number 1802.3081.02

Description

Upgrade of 4-channel R&S®MXO 5C series oscilloscope to 500 MHz bandwidth

R&S®MXO5C-B410

Order number 1802.3046.02

Description

Upgrade of 4-channel  R&S®MXO 5C series oscilloscope to 1 GHz bandwidth

R&S®MXO5C-B420

Order number 1802.3069.02

Description

Upgrade of 4-channel R&S®MXO 5C series oscilloscope to 2 GHz bandwidth

R&S®MXO5C-B802

Order number 1802.3117.02

Description

Upgrade of 8-channel R&S®MXO 5C series oscilloscope to 200 MHz bandwidth

R&S®MXO5C-B803

Order number 1802.3100.02

Description

Upgrade of 8-channel R&S®MXO 5C series oscilloscope to 350 MHz bandwidth

R&S®MXO5C-B805

Order number 1802.3098.02

Description

Upgrade of 8-channel R&S®MXO 5C series oscilloscope to 500 MHz bandwidth

R&S®MXO5C-B810

Order number 1802.3052.02

Description

Upgrade of 8-channel R&S®MXO 5C series oscilloscope to 1 GHz bandwidth

R&S®MXO5C-B820

Order number 1802.3075.02

Description

Upgrade of 8-channel R&S®MXO 5C series oscilloscope to 2 GHz bandwidth

General
Product
Description
R&S®MXO5C-B6

Order number 1802.3030.02

Description

Arbitrary waveform generator, 100 MHz, 2 analog channels

R&S®MXO5C-B1

Order number 1802.3023.02

Description

Mixed signal option for  R&S®MXO 5C series with 16 digital channels

R&S®MXO5C-B19

Order number 1803.1460.02

Description

Additional replacement SSD for R&S®MXO 5C series oscilloscope

Memory upgrade
Product
Description
R&S®MXO5C-B110

Order number 1803.1382.02

Description

Memory upgrade to 1 Gpoints for R&S®MXO 5C series oscilloscope

Serial triggering and decoding
Product
Description

Order number 1803.1418.02

Description

Low speed serial protocol trigger and decode package: I2C, SPI, UART, RS-232/422/485, Quad-SPI

Order number 1803.1424.02

Description

Automotive serial protocol trigger and decode package: CAN, CAN-FD, CAN-XL, LIN

Order number 1803.1447.02

Description

MIPI low speed serial protocol trigger and decode package: SPMI bus

Order number 1803.1453.02

Description

Automotive ethernet trigger and decode package: 10BASE-T1S  and 100BASE-T1

Order number 1803.1430.02

Description

Aerospace protocol serial trigger and decode package: ARINC429, MIL-1553

General analysis
Product
Description

Order number 1802.3130.02

Description

Power analysis

Order number 1802.3146.02

Description

Frequency response analysis (requires R&S®MXO5C-B6 as a source)

General
Product
Description
R&S®ZZA-KN2NS

Order number 1703.1498.00

Description

Rackmount kit for R&S®MXO 5C oscilloscopes with 2 HU

Passive probes
Product
Description

Order number 1333.1370.02

Description

Passive probe, 38 MHz, 1:1

Order number 1409.7550.00

Description

Passive probe, 500 MHz, 10:1

Order number 1333.2401.02

Description

Passive probe, 500 MHz, 10:1

Active single-ended probes
Product
Description

Order number 1418.7007.02

Description

Active single-ended probe, 1 GHz, Rohde & Schwarz probe interface

Order number 1410.4080.02

Description

Active single-ended probe, 1 GHz, R&S®ProbeMeter, Rohde & Schwarz probe interface

Order number 1410.3502.02

Description

Active single-ended probe, 1.5 GHz, R&S®ProbeMeter, Rohde & Schwarz probe interface

Active differential probes
Product
Description

Order number 1410.4715.02

Description

Active differential probe, 1 GHz, Rohde & Schwarz probe interface

Order number 1410.4409.02

Description

Active differential probe, 1.5 GHz, Rohde & Schwarz probe interface

Order number 1410.4609.02

Description

Active differential probe, 3.0 GHz, Rohde & Schwarz probe interface

Order number 1410.4744.02

Description

External attenuator

10:1, 2.0 GHz, 1.3 pF, 60 V DC, 42 V AC (peak) for R&S®RT-ZD20/30 probes. Included in R&S®RT-ZD10.

Power rail probes
Product
Description

Order number 1800.5006.02

Description

Power rail probe, 2 GHz, R&S®ProbeMeter, Rohde & Schwarz probe interface

2.0 GHz, 1:1, 50 kΩ, R&S probe interface

High voltage probes
Product
Description

Order number 1333.0873.02

Description

250 MHz passive high voltage probe

Order number 1409.7737.02

Description

400 MHz passive high voltage probe

Order number 1409.7720.02

Description

400 MHz passive high voltage probe

Order number 1800.2307.02

Description

200 MHz High voltage differential probe

Order number 1800.2107.02

Description

100 MHz High voltage differential probe

Order number 1800.2207.02

Description

200 MHz High voltage differential probe

Order number 1800.2007.02

Description

100 MHz High voltage differential probe

Current probes
Product
Description

Order number 1333.0850.02

Description

AC/DC 20 kHz current probe

Order number 1409.8204.02

Description

2 MHZ current probe

Order number 1409.7750K02

Description

10 MHZ current probe

Order number 1409.8210.02

Description

10 MHZ Current probe

Order number 1409.7766K02

Description

100 MHZ current probe

Order number 1409.8233.02

Description

100 MHZ current probe

Order number 1409.7772K02

Description

120 MHz current probe

Order number 1801.4932.02

Description

120 MHz current probe

Order number 1333.0844.02

Description

100 kHz current probe

Logic probes
Product
Description
R&S®RT-ZL04

Order number 1333.0721.02

Description

400 MHz logic probe

EMC near field probes
Product
Description

Order number 1147.2736.02

Description

E and H near-field probe set

Modular probe system
Product
Description

Order number 1800.4700.02

Description

Modular probe amplifier module, 1.5 GHz

Order number 1419.3005.02

Description

Modular probe amplifier module, 3 GHz

Probe accessories
Product
Description

Order number 1409.7789.02

Description

Power supply for probes

Power supply for R&S®RT-ZC10/20/30/31 probes, +/-12V DC, +/-2.5A

Order number 1326.3641.02

Description

3D probe positioner

3D positionier with central tensioning knob for easy clamping and positioning of probes (span width: 200 mm, clamping range: 15 mm)

Order number 1800.0004.02

Description

Power deskew fixture

Deskew fixture for voltage and current probes for power measurements; includes USB 2.0 cable for power supply

Order number 1801.4803.02

Description

Probe positioner with 2 legs

Related videos

Zone Trigger on Math

Use zone trigger to define trigger events graphically, also on your math signals. See how you can use this standard and unique capability on MXO oscilloscopes to trigger on specific events on your math signal.

25-Nov-2024

Zone Trigger

Use zone trigger to define trigger events graphically. See how you can use this standard feature on MXO oscilloscopes easily and reliably.

25-Nov-2024

Zone Trigger on Spectrum

Use zone trigger to define trigger events graphically, also in the frequency domain. See how you can use this standard and unique capability on MXO oscilloscopes to trigger on certain events in the frequency domain.

25-Nov-2024

Trigger and Decode on I2C Bus

Quickly and reliably trigger and decode packets from your I2C bus using either the analog or digital channels as serial bus inputs. See how you can flexibly configure the trigger, change the bit rate or threshold voltage or display a decode table.

27-Jun-2024

Frequency Response Analysis

This video shows how you can use the MXO Series K36 Frequency Response Analysis option to characterize the frequency response of your electric devices.

27-Jun-2024

Probe Positioners

This video shows you how you can better place and stabilize your probes using the the Rohde & Schwarz 2D positioner for passive probes and the 3D positioner for other probes.

27-Jun-2024

Trigger and Decode on SPI Bus

Quickly and reliably trigger and decode packets from your SPI bus using either the analog or digital channels as serial bus inputs. See how you can flexibly configure the trigger or display the decode table.

27-Jun-2024

Trigger and Decode on UART Bus

Quickly and reliably trigger and decode packets from your RS232 or RS485 buses using either the analog or digital channels as serial bus inputs. See how you can flexibly configure the trigger, change the data format or display a decode table.

27-Jun-2024

Request information

Do you have questions or need additional information? Simply fill out this form and we will get right back to you.

Marketing permission

Your request has been sent successfully. We will contact you shortly.
An error is occurred, please try it again later.
General and legal information

Manufacturer's recommended retail price (MSRP). The price shown does not include VAT. Prices and offers are only intended for entrepreneurs and not for private end consumers.

You may use the electronic signature via DocuSign to submit your information to enroll with the Rohde & Schwarz Customer Delegated Administration program. DocuSign processes the information provided according to their . The minimum system requirements for using the DocuSign system may change over time. The current system requirements are found

Terms & Conditions of the Prize Draw 10 years Rohde & Schwarz oscilloscopes

1. The prize draw “10 years Rohde & Schwarz oscilloscopes” (herein referred to as “Draw”) is organized by Rohde & Schwarz GmbH & Co. KG, Mühldorfstraße 15, 81671 Munich, Germany, Tel. +49 89 41 29 0 (herein referred to as “R&S).

2. All participators can register to the draw during January 01, 2020 to December 31, 2020 with their name, company name and business e-mail.

3. Participation is free of charge and not dependent on the purchase of goods or services.

4. The draw is only open to legal entities and only the legal entities are able to win the prizes. An individual person is not allowed to participate on its own name and its own account but as a representative of a legal entity filing the participation form in the name of and on behalf of the legal entity.

5. The prizes to win are 1 of 10 R&S®RTB2000 within the time frame January 1, 2020 to December 31, 2020:

Prize: 1x R&S®RTB2000 Digital Oscilloscope

6. The draw takes place at Rohde & Schwarz headquarters, Muehldorstrasse 15, 81671 Munich. The winner of the prizes will be informed by e-mail within 5 (5) working days.

7. The authorized representative of the legal entity shall inform Rohde & Schwarz about the acceptance of the price. In case of the denial of the acceptance, or no answer within two (2) weeks, a new winner will be drawn. If no winner can be determined within four (4) weeks, the draw ends and the prize forfeit.

8. R&S’ employees and members of their families and also person being familiar with the process of the draw and members of their families are excluded from filling the participation form.

9. No cash equivalent or exchange of prizes is allowed. Prizes are non-transferable. All taxes, levies, duties, fees and other charges levied in the participant´s country shall be borne by the participant.

10. Personal data will be processed only for the purpose of this prize draw and deleted four (4) weeks after the draw, if not agreed otherwise.

11. Any Participant who does not comply with these Terms & Conditions may be disqualified by R&S from this Competition. In such cases, prizes can also be withdrawn retrospectively. In case a prize is withdrawn retrospectively due to the non-compliance with these Terms & Conditions, it shall be returned by the respective participant at his cost to R&S’ address mentioned under Nr.1 and a new winner will be drawn.

12. The participants cannot claim the prizes of this draw and no legal recourse is permitted in this respect.

13. The draw and any contractual relationship arising therefrom between R&S and the respective participant shall be governed by and construed in accordance with the laws of Germany, without any recourse to the conflict of laws. The courts of Munich, Germany, shall have exclusive jurisdiction in case of any disputes arising directly or indirectly from the participation in this Competition.

* “fast delivery” inside 7 working days applies to the Rohde & Schwarz in-house procedures from order processing through to available ex-factory to ship.
