Key facts
- Bandwidth: 60 MHz to 500 MHz
- Sample rate: up to 5 Gsample/s
- Memory depth: up to 500 kpts, 50 Mpts segmented memory
- ADC resolution: 10-bit
- Isolated channels (CAT IV 600 V (RMS) / CAT III 1000 V (RMS))
Starting at 3 740 €
Key facts
Starting at 3 740 €
When debugging embedded devices in the lab or analyzing complex problems in the field, the R&S®Scope Rider offers the performance and capabilities of a lab oscilloscope as well as the form factor and ruggedness of a battery-operated handheld device. Isolated channels combined with 500 MHz bandwidth makes it a perfect choice for power electronics applications. An integrated multimeter (two-channel model) or a multimeter mode (four-channel model) make the instrument the perfect tool for troubleshooting all kinds of electronics problems.
Quick links
Lab performance in a rugged, portable design
When debugging embedded devices in the lab or analyzing complex problems at the customer site, the R&S®Scope Rider offers the performance and capabilities of a lab oscilloscope as well as the form factor and ruggedness of a battery-operated handheld device.
Debugging power in your hands
With the power of eight instruments, R&S®Scope Rider provides the capabilities and the flexibility needed to debug all kinds of electronic systems in the lab and in the field.
Capacitive touchpad and keypad operation
Making use of the latest display technology, R&S®Scope Rider offers a crystal-clear signal display with a high-resolution capacitive touch color display.
CAT IV 600 V/CAT III 1000 V in an IP51 housing
Isolated inputs with CAT IV 600 V/CAT III 1000 V rating allow safe measuring in all environments.
And much more
Wireless LAN* and Ethernet for web-based remote control, easy documentation of measurement results and more than four hours of battery power make the R&S®Scope Rider the right tool for your everyday troubleshooting needs in the lab and in the field.
* Not available in all countries. For more information, see our datasheet.
Order number 1317.5000P02
Order number 1317.5000P04
Order number 1317.5000P12
Order number 1317.5000P14
Order number 1317.5000P22
Order number 1317.5000P24
Order number 1317.5000P32
Order number 1317.5000P34
Order number 1317.5000P52
Order number 1317.5000P54
Vertical system | ||
Analog channels | R&S®RTH1002 R&S®RTH1012/R&S®RTH1022 R&S®RTH1032/R&S®RTH1052 |
2 |
R&S®RTH1004/R&S®RTH1014/R&S®RTH1024/R&S®RTH1034/R&S®RTH1054 | 4 | |
Digital channels (opt.) | 8 | |
Bandwidth (-3 dB) | R&S®RTH1002 and R&S®RTH1004 R&S®RTH1012 and R&S®RTH1014 R&S®RTH1022 and R&S®RTH1024 R&S®RTH1032 and R&S®RTH1034 R&S®RTH1052 and R&S®RTH1054 |
60 MHz, 100 MHz, 200 MHz, 350 MHz, 500 MHz |
Rise time | R&S®RTH1002 and R&S®RTH1004 R&S®RTH1012 and R&S®RTH1014 R&S®RTH1022 and R&S®RTH1024 R&S®RTH1032 and R&S®RTH1034 R&S®RTH1052 and R&S®RTH1054 |
60 MHz, <5.8 ns 100 MHz, <3.5 ns 200 MHz, <1.75 ns 350 MHz, <1 ns 500 MHz, <700 ps |
Input impedance | 1 MΩ ± 1 % || 12 pF ± 2 pF (meas.) | |
Input sensitivity | 2 mV/div to 100 V/div | |
ADC resolution | 10 bit | |
Offset range | +/-200 V | |
Maximum input voltage | CAT IV 300 V (RMS), 424 V (Vp) CAT IV 600 V, CAT III 1000 V |
|
Acquisition system | ||
Realtime sampling rate | 1/2/4 channels active | 5/2.5/1.25 Gsample/s |
Acquisition memory | 1/2/4 channels active | 500/250/125 ksample/channel |
Max. acquisition rate | 50,000 waveforms/s | |
Decimation modes | sample, high resolution, peak detect | |
Waveform arithmetics | envelope, average | |
Horizontal system | ||
Timebase range | 1 ns/div to 500 s/div | |
Accuracy (after delivery/calibration) | ±10 ppm | |
Channel deskew | ±100 ns | |
Trigger system | ||
Standard Trigger types | edge, glitch, width | |
Optional Trigger types | TV/Video, pattern, state, runt, slew rate, window, Data2clock, serial pattern, timeout, interval, protocol | |
Analysis and measurement functions | ||
Automatic measurements | 37 measurement functions | |
Mask testing | ||
Mask definition | tolerance tube | |
Actions on violation | none, beep, stop | |
History and segmented memory | ||
Number of segments | up to 5000 | |
Protocol trigger and decode | ||
Supported protocols | (optional: R&S®RTH-K1, R&S®RTH-K2, R&S®RTH-K3, R&S®RTH-K9, R&S®RTH-K10) | I2C, UART/RS-232/RS-422/RS-485, CAN, LIN, CAN-FD, SENT |
Logic analyzer (MSO) functionality | ||
Digital input channels | 8 | |
General data | ||
Dimensions | W x H x D | 201 mm x 293 mm x 74 mm (7.91 in x 11.54 in x 2.91 in) |
Weight | with battery | 2.4 kg (5.3 lb) (nom.) |
Display | 7.0" LC TFT 800 x 480 color display | |
Interfaces | USB host, USB device, LAN, wireless LAN (optional) | |
Operating system | Embedded | |
Data logger | ||
Number of simult. logging channels | 4 | |
Measurement speed | 1/2/5 measurements/s | |
Memory depth | 2 Msample per logging channel | |
Digital voltmeter/digital multimeter | ||
Resolution | 2-channel version (digital multimeter): 11 000 counts 4-channel version (digital voltmeter): 999 counts |
|
Voltage and current | current with optional current probe or shunt | DC, AC, AC+DC |
Temperature | with PT100 temperature sensor | |
IP rating | IP51, in line with IEC 60529 |
Order number 1325.9981.02
Mixed signal option: 250 MHz
Turns the R&S®RTH oscilloscopes into fast, precise and portable mixed signal oscilloscopes (MSO).
Order number 1325.9717.02
Bandwidth upgrade of the R&S®RTH1002 to 100 MHz
Order number 1325.9723.02
Bandwidth upgrade of the R&S®RTH1002 to 200 MHz
Order number 1325.9730.02
Bandwidth upgrade of the R&S®RTH1002 to 350 MHz
Order number 1326.0571.02
Bandwidth upgrade of the R&S®RTH1002 to 500 MHz
Order number 1326.0588.02
Bandwidth upgrade of the R&S®RTH1004 to 100 MHz
Order number 1326.0594.02
Bandwidth upgrade of the R&S®RTH1004 to 200 MHz
Order number 1326.0607.02
Bandwidth upgrade of the R&S®RTH1004 to 350 MHz
Order number 1326.0613.02
Bandwidth upgrade of the R&S®RTH1004 to 500 MHz
Order number 1325.9969.02
I²C/SPI triggering and decoding
Analysis of I2C and SPI signals on analog and logic channels.
Order number 1325.9975.02
UART/RS-232 triggering and decoding
Analysis of UART/RS-232/422/485 signals on analog and logic channels.
Order number 1333.0550.02
CAN/LIN triggering and decoding
Analysis of CAN and LIN signals on analog and logic channels.
Order number 1326.3829.02
CAN-FD triggering and decoding
Analysis of CAN-FD signals on analog and logic channels. Requires R&S®RTH-K3.
Order number 1326.3835.02
SENT triggering and decoding
Analysis of SENT signals on analog and logic channels.
Order number 1326.1803.02
History and segmented memory
Order number 1333.0680.02
Spectrum analysis
Order number 1326.0642.02
Advanced trigger
Order number 1333.0696.02
Frequency counter
Order number 1333.0673.02
Harmonic analysis
Order number 1801.4632.02
User scripting
Order number 1326.0620.02
Wireless LAN, all countries except US, Canada and EU
Order number 1332.9890.02
Wireless LAN, for US and Canada, only
Order number 1326.0636.02
Web interface remote control
Order number 1333.0809.02
PT100 temperature probe (4 mm Banana plug)
Order number 1326.1978.02
Accessory replacement set for R&S®RT-ZI10 and R&S®RT-ZI11
Contains push-on hook clip, push-on reference contact, reference lead with crocodile clip, push-on insulating sleeve, set of color clips.
Order number 1326.1984.02
Accessory extension set for R&S®RT-ZI10 and R&S®RT-ZI11
Contains test clip with steel jaws, push-on safety jaw clip, silicone-insulated reference leads, push-on Ø 4 mm test probe, Ø 2 mm reference lead with hook clip, BNC male connector to Ø 4 mm sockets, push-on BNC male connector.
Order number 1326.0988.02
Safety test leads, red and black, silicone, 600 V CAT IV
Order number 1309.6175.00
Carrying bag
Order number 1309.6152.00
Spare LAN cable
Order number 1309.6169.00
Spare USB cable
Order number 1326.2774.02
Hard shell protective carrying case
Dimensions: 455 mm x 368 mm x 166 mm. Weight: 2.5 kg.
Order number 1321.1340.02
Power supply for vehicles
Powers the instrument and the R&S®HA-Z303 external battery charger
Order number 1321.1328.02
External battery charger
Charges batteries outside of the instrument
Order number 1321.1334.02
Battery pack
Lithium-ion battery with discharge indicator, 6.4 Ah
Order number 1326.2874.02
Spare power supply for R&S®Scope Rider
Order number 1800.2707.00
Accessory kit for R&S®RT-ZHD probes and R&S®Scope Rider multimeter
Contains 2 x safety alligator clip, 2 x pincer clip, 2 x test clip, 2 x spade terminal, 2 x lead 17 cm, 2 x lead 100 cm
Order number 1326.1761.02
Passive probe, 500 MHz, 10:1, isolated
Order number 1326.3106.02
Compact passive probe, 500 MHz, 10:1, isolated
Order number 1326.1810.02
Passive probe, 500 MHz, 100:1, isolated
Order number 1333.0850.02
AC/DC 20 kHz current probe
Order number 1333.0844.02
100 kHz current probe
Order number 1801.4932.02
120 MHz current probe
Order number 1801.3242.02
Application bundle (R&S®RTH-K1, K2, K3, K9, K10, K15, K18, K19, K33, K34, K38 and K201)
Contains trigger and decoding I²C/SPI (R&S®RTH-K1), UART/RS-232 (R&S®RTH-K2), CAN/LIN (R&S®RTH-K3), CAN-FD (R&S®RTH-K9), SENT (R&S®RTH-K10), history and segmented memory (R&S®RTH-K15), spectrum analysis (R&S®RTH-K18), advanced trigger (R&S®RTH-K19), frequency counter (R&S®RTH-K33), harmonic analysis (R&S®RTH-K34), user scripting (R&S®RTH-K38) and web interface remote control (R&S®RTH-K201) for R&S®RTH models
Order number 1338.0413.02
Power electronics bundle (R&S®RTH-K15, -K19, -K34)
Power electronics bundle, contains history and segmented memory (R&S®RTH-K15), advanced triggering (R&S®RTH-K19) and harmonics analysis (R&S®RTH-K34)
Order number 1338.0436P02
Industrial bundle (R&S®RTH-Z4; R&S®HA-Z303, -Z306)
Industrial bundle, contains hard shell protective carrying case (R&S®RTH-Z4), battery charger for lithium-ion battery (R&S®HA-Z303) and replacement lithium-ion battery pack (R&S®HA-Z306)
Order number 1338.0420.02
Automotive bundle (R&S®RTH-K3, -K9, -K10)
Automotive bundle, contains trigger and decoding CAN/LIN (R&S®RTH-K3), CAN-FD (R&S®RTH-K9) and SENT (R&S®RTH-K10)
