R&S®AREG100A automotive radar echo generator

Key facts

Supports 24 GHz, 77 GHz and 79 GHz automotive radar sensors
Future proof with instantaneous bandwidths of up to 4 GHz
4 m minimum artificial object distance for short range radar testing
Up to 4 artificial objects in fixed distances at the same time
Controllable radial velocity for each artificial object individually or for all artificial objects together

Get pricing Configure your product

Reliable production testing of automotive radar sensors made easy

The R&S®AREG100A Automotive Radar Echo Generator is a smart and robust solution for testing automotive radar sensors in production. With the R&S®AREG100A, production engineers profit from a perfect balance of flexibility of test cases and at the same time simple and robust operation.

I    Supports all automotive radar bands
I    4 GHz instantaneous bandwidth
I    4 m minimum artificial object distance

Quick links

Show available options
Show all downloads

Features & benefits

Reliable and flexible echo generation

Install up to four different, customer defined fixed delay lines to simulate unrelated object echoes
Simulate echoes with minimum delay for short range radar (SRR) sensor tests
Simulate echoes for long range radar (LRR) sensor tests
Select additional Doppler offsets to simulate radial velocity for each artificial object individually or for all artificial objects together

With the R&S®AREG100A it has never been easier to monitor the quality of automotive radar sensors in mass production.

Test today’s and tomorrow’s radar sensors

Choose a 24 GHz ISM band frontend, an E-band frontend or both together for sequential operation
Profit from a future proof wideband E-band frontend with 4 GHz instantaneous bandwidth for short range radar (SRR) sensor test
All frontends in a single antenna configuration for superior MIMO testing performance or in a two antenna configuration with high RX/TX isolation for lowest ringaround.

R&S®AREG100A with single antenna frontend for reliable testing of MIMO radar sensors

Ready for RED

Measure the sensor’s equivalent radiated isotropic power (EIRP) in line with the applicable standards with a connected R&S NRP8S(N) power sensor
Verify robustness of radar sensors against in-band interferers with a connected analog or vector signal generator
Measure occupied bandwidth and unwanted emissions with a connected signal and spectrum analyzer

The R&S®AREG100A and the R&S®FSW8 are the perfect team for convenient measurement of radar signal parameters in the E band.

Simple and stable operation

Linux based operating system for maximum software stability
Optimized for minimum footprint with just 3 HUs
SCPI macro recorder with automatic code generator
Intuitive GUI for user friendly operation

Simple man-machine interface for user friendly configuration with intuitive GUI and toch screen control

Specifications

Frequency
Frequency range	R&S®AREG-B124S/-B124D	24 GHz to 24.25 GHz, single or dual antenna
	R&S®AREG-B177S/-B177D	76 GHz to 77 GHz, single or dual antenna
	R&S®AREG-B181S/-B181D	76 GHz to 81 GHz, single or dual antenna
Signal bandwidth
Instantaneous bandwidth	R&S®AREG-B124S/-B124D	250 MHz
	R&S®AREG-B177S/-B177D	1 GHz
	R&S®AREG-B181S/-B181D	4 GHz from 76 GHz to 81 GHz (configurable: either 76 GHz to 80 GHz or 77 GHz to 81 GHz)
Artificial objects
Object type		fixed distance
Total number of objects		4
Object distances	up to one R&S®AREG-B61 option	4 m (incl. 0.8 m air gap between R&S®AREG frontend and radar under test)
	up to three R&S®AREG-B62 options, distance for each option has to be defined during ordering process	5 m to 300 m (incl. 0.8 m air gap between R&S®AREG frontend and radar under test); customer definable during ordering process
Air gap to device under test		It is recommended that antennas be positioned in far field; customer definable during ordering process
Radial velocity
Doppler frequency shift	With R&S®AREG-K799 Doppler frequency shift for all artificial objects together	yes
Individual Doppler frequency shift	With R&S®AREG-B60 Doppler frequency shift for each artificial object individually	yes
Velocity setting range	R&S®AREG-B60 and R&S®AREG-K799	+/- 500 km/h
Level
Absolute maximum RX power at frontend RX waveguide port	R&S®AREG-B124S/-B124D	0 dBm (nom.)
	R&S®AREG-B124S/-B124D	–7 dBm (nom.)
	R&S®AREG-B181S/-B181D	–7 dBm (nom.)
Maximum TX power at frontend TX waveguide port	R&S®AREG-B124S/-B124D	≥ 15 dBm (meas.)
	R&S®AREG-B177S/-B177D	≥ 20 dBm (meas.)
	R&S®AREG-B181S/-B181D	≥ 18 dBm (meas.)
Receive/transmit gain control setting range	all artificial objects together	> 90 dB (meas.)
Receive/transmit gain control setting range	each artificial object individually	55 dB (meas.)
Receive/transmit gain control step size		0.5 dB (nom.)
IF input/IF output
IF input/output interfaces	with R&S®AREG-B17 option	calibrated IF outputs on frontend and base unit; calibrated IF input on base unit
IF input gain from auxiliary TX IF In port (at IF frequency) to frontend TX waveguide output (at RF frequency)	R&S®AREG-B124S/-B124D, RF frequency = 24.125 GHz	20 dB (meas.)
	R&S®AREG-B177S/-B177D, RF frequency = 76.5 GHz	20 dB (meas.)
	R&S®AREG-B181S/-B181D, RF frequency = 78 GHz or 79 GHz	20 dB (meas.)
IF input compression P1dB level at TX IF In port (at IF frequency)	R&S®AREG-B124D	1 dBm (meas.)
	R&S®AREG-B177D	1 dBm (meas.)
	R&S®AREG-B181D	-5 dBm (meas.)
Connectivity
Remote control		Ethernet
	with R&S®AREG-B86 option	GPIB, USB
