R&S®AdVISE Visual Inspection Software

Cut out human lack of attention errors

R&S®AdVISE Visual Inspection Software
Open Lightbox
R&S®AdVISE Visual Inspection Software, Screenshot

Key facts

  • Automated EUT monitoring based on camera signal evaluation
  • Continuous monitoring of up to 16 or 32 (optional) regions on the EUT in parallel
  • Optional image tracking to compensate for EUT and camera vibrations
  • Creation of event-controlled video protocols and test reports
  • Optional automatic event detection based on machine learning

At a glance

R&S®AdVISE visual inspection software automates the process of visually monitoring equipment under test (EUT) during a test sequence. This eliminates errors due to human inattention, ensures reproducible results and simplifies test documentation. A typical application is EMS testing with R&S®ELEKTRA EMC automation software.

Features & benefits

System concept

Flexible and economical

  • Runs on any Windows 10 controller that fulfills the minimum system requirements
  • Video grabbing via off-the-shelf portable frame grabber HW
  • Supports the use of a multiviewer to analyze in parallel the video of up to four cameras

Wide range of powerful test methods

Regions of interests

Regions of interest (ROI) are the mechanism by which the user defines how to use the R&S®AdVISE system. A wide range of analytical methods covers a broad spectrum of visual inspection:

  • Automatic event detection assistant (uses artificial intelligence)
  • Presence or absence of symbols and icons
  • Indicator brightness and color
  • Analog indicator position
  • Flashing indicator characteristics
  • Start/Stop of motion
  • Disturbance of displays
  • Optical Character Recognition (OCR) for text and numbers (optional)
  • Audio monitoring - Check of wanted or unwanted noise in frequency or time domain (optional)

Automatic event detection assistant

Artificial intelligence inside for time-saving setup routines. Optional R&S®ADV-K1080

The optional automatic event recognition assistant ROI eliminates the need to select and configure individual ROIs. Based on machine learning, using a short recording of the desired behavior of the EUT as training material, the ROI automatically detects and marks events in the video stream that may contain faulty behavior. The user, then, approves or discards the suggestions of the automatically detected events.

Image tracking

Optional R&S®ADV-K1062

Automate visual inspection, even if running motors, shaky turntable or unstable camera suspension causes image vibrations. Also simplifies camera repositioning

Video protocol and test report

Integrated protocol utilities

R&S®AdVISE creates a video protocol and an event list. What sets the system apart in usability is the indexing feature of the integrated video player. This feature allows the user to go to any event in the video just by clicking on the event information. The player also enables the user to collect a single frame as a JPEG image and to collect a clip of the video to be used for reports or archiving. The event list itself can be saved as a PDF test report.

Event controlled video protocol
Open Lightbox

Event controlled video protocol

Show any event in the video by cklicking on the event information

Remote control

R&S®AdVISE has a generic and an extended remote control interface to control test sequences

Generic remote control interface:

  • Open for any external control software
  • Passes summary Go/NoGo information to the control software
  • Control software can transmit test information to be inserted into the incoming and recorded video
Extended remote control interface:
  • Supported in R&S EMC control software R&S®ELEKTRA
  • Provides, in addition to the generic remote control interface, the test results of the individual ROIs for graphical processing in R&S®ELEKTRA

Measurement view overlaid EMS test conditions
Open Lightbox

Measurement view overlaid EMS test conditions

Available options

Base unit
Product
Description
R&S®ADVISE-PC

Order number 1434.6660.02

Description

License dongle

R&S®ADVISE-SW

Order number 1434.6518.02

Description

Visual inspection software

Software options
Product
Description
R&S®ADV-K1032

Order number 1434.6524.02

Description

Extension to 32 ROI

R&S®ADV-K1050

Order number 1434.6530.02

Description

Virtual camera

R&S®ADV-K1060

Order number 1434.6601.02

Description

ROI Optical caracter recognition for text and numbers

R&S®ADV-K1062

Order number 1434.6618.02

Description

ROI Audio

R&S®ADV-K1070

Order number 1434.6560.02

Description

Image Tracking

R&S®ADV-K1080

Order number 1434.6576.02

Description
