Broadcast standards instrument options

broadcast signal generation

Key facts

Broadcast signals for component and receiver testing
Support of FM, DAB, DVB-T2 and other broadcast standards
Generation of analog and digital audio / video broadcast signals
All broadcast frequency bands covered
Support of second and third generation broadcast standards

Get a Quote

Generation of realistic broadcast signals

Comprehensive testing of globally used broadcast equipment

When vector signal generators from Rohde & Schwarz are fitted with broadcast signal generation options, they provide innovative measurement solutions for testing broadcast receivers in R&D and production. They test on the physical layer and on the application layer using the most common broadcast transmission standards. Solutions from Rohde & Schwarz are ideal for characterization and validation, meeting customer performance, cost and scheduling needs.

Quick links

Show available models

Features & benefits

Test like it's real

Realistic broadcast signals

Depending on the requirements, broadcast signals can either be generated in real time by means of an FPGA or an arbitrary waveform application. The real-time coder generates an uninterrupted signal flow and is ideal for audio, video and bit error rate tests with long PRBS on the application layer. The arbitrary waveform generator with I/Q waveforms can be used to perform tests that focus mainly on the physical layer.

**FM signal generation with the R&S®SMCV100B** - With the ability to generate signals for all relevant broadcast standards, the R&S®SMCV100B is ideal for lab and production testing.

Largest choice of broadcast standards

Easy adaption to regional or global requirements

The large number of available broadcast standards can be combined in a perfect matching configuration by software options. Many signal generators from Rohde & Schwarz support broadcast standards as real-time, arbitrary waveform generator solutions or WinIQSIM2.

**Selection of available broadcast standards.** - Analog and digital audio and video broadcast standards are supported by a variety of Rohde & Schwarz signal generators as here on the R&S®SMCV100B.

Real-time signal generation

Broadcast signals with real-time audio/video content and services

Real-time signal generation is available on dedicated Rohde & Schwarz signal generators and uses FPGA for a wide range of broadcast standards. This enables users to select standard related streams such as ETI, MPEG-2 TS and others with encoded audio/video content. Encoded audio and video signals from external sources can also be used. Broadcast real-time coders provide a constant, present signal without interruption when compared to arbitrary waveform generators.

**Parameter setting in DVB-T2 on the R&S®SMCV100B.** - Full signal configuration flexibility with access to broadcast standard transmission parameters.

Testing receiver application layers

Broadcast streaming libraries with audio, video and data content

Real-time coders use encoded audio, video and data content as their input signal. Such content enables broadcast receiver testing on the application layer by including the transmission channel and the lower layers. These end-to-end tests are important to ensure the user experience on the system level. A number of Rohde & Schwarz signal generators support these streaming libraries in addition to the real-time coders.

**Selection of Rohde & Schwarz streaming libraries.** - Users can download Rohde & Schwarz streaming libraries from the Rohde & Schwarz customer web, allowing them access to the latest updates.

Testing broadcast receivers with I/Q waveforms

I/Q waveforms with R&S®WinIQSIM2™, waveform libraries and predefined signals

I/Q waveforms are ideal for user-friendly receiver testing. Depending on the broadcast standard and its bandwidth, these waveforms can be used for verification tests on the application layer such as HD Radio™ or for simple function tests on the physical layer. HD Radio™, XM Radio and predefined waveforms can be selected. R&S®WinIQSIM2™ offers several broadcast standards as well. I/Q waveforms are supported by a number of Rohde & Schwarz signal generators with arbitrary waveform generator functions.
